Description
xGoodWe GT Series 125kW Inverter
The GoodWe GT 125kW inverter is a high-performance three-phase string inverter, purpose-built for commercial and industrial (C&I) solar PV applications. With up to 10 MPPTs, a maximum efficiency of 99%, and support for 21A per string input current, it is optimized to work seamlessly with today’s high-power PV modules.
Engineered for maximum energy yield and reliability, the inverter allows 150% DC input oversizing and 110% AC output overloading, ensuring superior flexibility in system design. Its IP66-rated enclosure with optional C5 protection makes it suitable for harsh outdoor conditions.
Safety is a top priority: the GT 125kW features Type II surge protection (AC & DC sides), integrated DC switch, residual current monitoring, and optional AFCI & rapid shutdown functions. With smart monitoring, remote upgrade capabilities, and user-friendly maintenance (lightweight design, fan replacement), this inverter offers the ideal balance of performance, safety, and reliability for large-scale PV projects.
Specifications – GoodWe GT 125kW (GW125K-GT)
| Category | Specification |
|---|---|
| Input (DC) | |
| Max. Input Voltage | 1100 V |
| MPPT Operating Voltage Range | 180 ~ 1000 V |
| Start-up Voltage | 200 V |
| Nominal Input Voltage | 600 V |
| Max. Input Current per MPPT | 42 A |
| Max. Short Circuit Current per MPPT | 52.5 A |
| Number of MPPTs | 10 |
| Strings per MPPT | 2 |
| Output (AC) | |
| Nominal Output Power | 125 kW |
| Nominal Apparent Power | 125 kVA |
| Max. AC Active Power | 137.5 kW (regional limits apply) |
| Max. AC Apparent Power | 137.5 kVA |
| Nominal Voltage | 220/380 V, 230/400 V (3L/N/PE or 3L/PE) |
| Output Voltage Range | 304 ~ 460 V |
| Nominal Grid Frequency | 50 / 60 Hz |
| Frequency Range | 45–55 / 55–65 Hz |
| Max. Output Current | 199.4 A |
| Power Factor | ~1 (0.8 leading to 0.8 lagging adjustable) |
| THD | <3% |
| Efficiency | |
| Max. Efficiency | 99.0% |
| European Efficiency | 98.5% |
| Protection Features | |
| DC/AC Surge Protection | Type II (Type I+II optional) |
| DC Switch | Integrated |
| AFCI | Optional |
| Residual Current Monitoring | Integrated |
| PV Reverse Polarity Protection | Integrated |
| Anti-islanding Protection | Integrated |
| Overcurrent & Short-circuit Protection | Integrated |
| Emergency Power Off | Optional |
| Rapid Shutdown | Optional |
| PID Recovery | Optional |
| General Data | |
| Operating Temperature | -30°C ~ +60°C |
| Relative Humidity | 0–100% |
| Max. Altitude | 4000 m |
| Cooling | Smart Fan Cooling |
| User Interface | LED, LCD (optional), WLAN + App |
| Communication | RS485, WiFi + LAN (4G/PLC optional) |
| Communication Protocols | Modbus-RTU (SunSpec compliant) |
| Weight | 88 kg |
| Dimensions (W×H×D) | 930 × 650 × 300 mm |
| Topology | Non-isolated |
| Self-consumption at Night | <2 W |
| Ingress Protection | IP66 |
| DC Connector | MC4 (4–6mm²) |
| AC Connector | OT/DT terminal (Max. 240mm²) |
